PVQ叶片泵(力士乐)
  • PVQ叶片泵(力士乐)
  • PVQ叶片泵(力士乐)
  • PVQ叶片泵(力士乐)

PVQ叶片泵(力士乐)

产品介绍产品型号



  力士乐PVQ系列叶片泵特点:

  1.定排量;

  2.由于液压卸荷的轴而使轴承拥有长寿命;

  3.由于液压卸荷的叶片而仅有很小的磨损;

  4.工作噪音低;

  5.由于泵芯的互换性,有利于售后服务;

  6.好的效率;

  7.压油口的位置可以选择;

  8.驱动转向或右旋或左旋;

  9.驱动轴可选圆柱形或花键。

  力士乐PVQ系列叶片泵型号说明:

  规格18至193

  运行噪音低

  振动小

  适合多种不同速度和粘度范围

  可提供联轴泵

  可和轴向柱塞泵和内啮合齿轮泵连接使用

  力士乐PVQ系列叶片泵双联泵:

  1.极紧凑的结构;

  2.压油口的位置可分开选择。

  力士乐PVQ系列叶片泵系列说明:

  ⑴、系列号 PV

  ⑵、用途类别 V:工业款 Q:行走机械式

  ⑶、机型规格 1、2、4、5

  ⑷、元件系列号 10~19,安装尺寸不变

  ⑸、排量 (cm?/rev)4:069、082、098、113、122

  ⑹、旋转方向 R:顺时针 L:逆时针

  ⑺、轴伸形式 A:直轴(标准) B:重型轴 J:花键

  ⑻、油口螺纹 15

  ⑼、油口方向 (盖端看)D:上(标准) R:右 L:左 U:下

  ⑽、密封材料 M:丁橡胶 V:氟橡胶

  ⑾、安装形式 (1、2):B (4、5):C

力士乐PVQ叶片泵型号:

PVQ21-1X/040-046LJ15RRMB
PVQ2-1X/040LJ15DMB
PVQ21-1X/055-027RA15DDMB
PVQ21-1X/040-046RJ15RRMB
PVQ21-1X/068-018RB15DDMB
PVQ21-1X/055-027RJ15DDVB
PVQ2-1X/060RJ15UMB
PVQ21-1X/055-018LJ15DDMB
PVQ2-1X/068RA15DMB
PVQ21-1X/068-027RA15DDMB
PVQ2-1X/055RA15UMB
PVQ21-1X/068-036RA15DDMB
PVQ21-1X/068-046RA15DDMB
PVQ2-1X/060RA15DMB
PVQ21-1X/068-040RA15DDMB
PVQ2-1X/060RA15UMB
PVQ2-1X/068RJ15UMB
PVQ2-1X/055RJ15UMB
PVQ21-1X/068-027RJ15UUMB
PVQ21-1X/055-046LJ15RRMB
PVQ21-1X/040-018RJ15DDMB
PVQ2-1X/040RA15DMB
PVQ21-1X/040-027RA15DDMB
PVQ2-1X/040RA15UMB
PVQ2-1X/068RA15UMB
PVQ21-1X/068-036RA15RDMB
PVQ2-1X/045LJ15DMB
PVQ21-1X/068-027LJ15UUMB
PVQ2-1X/068LJ15DVB
PVQ21-1X/068-027RA15RUMB
PVQ2-1X/045RA15DMB
PVQ2-1X/045RA15UVB
PVQ21-1X/055-027RA15UUMB
PVQ21-1X/060-027RA15UUVB
PVQ2-1X/068LJ15RMB
PVQ2-1X/040RJ15UMBK01
PVQ2-1X/045RJ15UMBK01
PVQ2-1X/045RB15DMB
PVQ21-1X/040-040RA15DDMB
PVQ21-1X/045-027RA15DDMB
PVQ2-1X/045RA15UMB
PVQ2-1X/068RB15UMB
PVQ2-1X/055RA15UVB
PVQ2-1X/055LJ15UMB
PVQ21-1X/068-046RA15UUMB
PVQ21-1X/055-027RJ15LLMB
PVQ21-1X/060-027RJ15LDMB
PVQ21-1X/068-036RJ15LDMB
PVQ21-1X/055-027RJ15LDMB
PVQ21-1X/060-036RJ15LDMB
PVQ21-1X/045-018RJ15LDMB
PVQ21-1X/045-036RJ15LDMB
PVQ2-1X/040RJ15RMB
PVQ21-1X/045-046RJ15LDMB
PVQ21-1X/068-046RJ15LDMB
PVQ21-1X/045-046RA15DDMB
PVQ2-1X/055RJ15DVB
PVQ21-1X/055-046RJ15LDMB
PVQ2-1X/068LA15LMB
PVQ21-1X/040-036RJ15UUMB
PVQ2-1X/045LJ15RMB
PVQ21-1X/060-027RB15DDMB
PVQ2-1X/068LB15DMB
PVQ21-1X/068-036RA15DLMB
PVQ21-1X/055-018RJ15DDMB
PVQ2-1X/068RJ15DMB
PVQ21-1X/055-040RJ15DDMB
PVQ2-1X/055RA15DMB
PVQ21-1X/055-018RA15DDMB
PVQ2-1X/040RJ15DMBK01
PVQ2-1X/040RB15UMBK02
PVQ2-1X/040RJ15UMB
PVQ21-1X/040-027RJ15DDMB
PVQ2-1X/045RB15UMB
PVQ2-1X/045LA15DMB
PVQ21-1X/045-046RA15UUMB
PVQ2-1X/040LJ15UMB
PVQ21-1X/055-018RB15DDMB
PVQ21-1X/055-036LJ15LLMB
PVQ2-1X/068LJ15UMB
PVQ2-1X/045RB15UMB-C3.1
PVQ2-1X/068LA15DMB
PVQ21-1X/040-018RB15RDMB
PVQ2-1X/060LJ15UMB
PVQ2-1X/055RB15DMB
PVQ2-1X/055RJ15DMB
PVQ21-1X/055-027LJ15DDMB
PVQ2-1X/045RJ15DMB
PVQ4-1X/098LJ15RMC
PVQ4-1X/082LJ15RMC
PVQ4-1X/098LJ15UMC
PVQ4-1X/082RJ15DMC
PVQ4-1X/098RA15UMC
PVQ4-1X/082RA15UMC
PVQ4-1X/122RA15DMC
PVQ4-1X/098RA15DMC
PVQ4-1X/069RA15DMC
PVQ4-1X/113RA15DMC
PVQ4-1X/082RJ15UMC
PVQ4-1X/098RJ15UMC
PVQ4-1X/122RA15UMC
PVQ4-1X/113RJ15UMC
PVQ4-1X/082RA15DMC
PVQ4-1X/069RJ15DMC
PVQ4-1X/122RA15UVC
PVQ4-1X/122LJ15DMC
PVQ4-1X/122LJ15RMC
PVQ4-1X/069RA15UMC
PVQ4-1X/122RJ15UMC
PVQ4-1X/122RA15RMC
PVQ4-1X/113RA15UMC
PVQ4-1X/122RJ15DMC
PVQ4-1X/069LJ15RMC
PVQ4-1X/069RJ15UMC
PVQ4-1X/098RJ15DMC
PVQ4-1X/082LB15DMC
PVQ4-1X/082RJ15LMC
PVQ4-1X/082LJ15DMC
PVQ4-1X/069LJ15DMC
PVQ4-1X/122RJ15UVC
PVQ4-1X/082RJ15UMCK01
PVQ4-1X/113RJ15DMC
PVQ4-1X/069RA15RMC
PVQ4-1X/069RJ15LMC
PVQ4-1X/098RB15DMC
PVQ4-1X/122RA15DMC
PVQ4-1X/098RB15RMCK07
PVQ4-1X/082LJ15UMC
PVQ4-1X/098RA15RMC
PVQ4-1X/113LA15DMC
PVQ4-1X/098RJ15RMCK02
PVQ4-1X/122LA15LMC
PVQ4-1X/069LA15DMC
PVQ4-1X/082LJ15DVC
PVQ41-1X/113-018LJ15DDMC
PVQ41-1X/098-046LJ15RRMC
PVQ41-1X/082-036LJ15RRMC
PVQ41-1X/113-040RB15DDMC
PVQ41-1X/098-036RJ15UUMC
PVQ41-1X/082-027RJ15UDMC
PVQ41-1X/082-018RJ15UDMC
PVQ41-1X/098-018RA15DDMC
PVQ41-1X/069-018RJ15UUMC
PVQ41-1X/069-027LJ15DDMC
PVQ41-1X/082-027RJ15UUMC
PVQ41-1X/113-018RB15UUMC
PVQ41-1X/082-018RA15DDMC
PVQ41-1X/098-027RA15DDMC
PVQ41-1X/098-046RA15DDMC
PVQ41-1X/098-036RJ15LDMC
PVQ41-1X/098-018LJ15UUMC
PVQ41-1X/098-046RJ15LDMC
PVQ41-1X/098-036RA15DDMC
PVQ41-1X/098-018RJ15UDMC
PVQ41-1X/113-027LJ15DDMC
PVQ41-1X/113-036RA15LLMC
PVQ41-1X/122-036RJ15DDMC
PVQ41-1X/122-027RJ15UUMC
PVQ41-1X/113-027RA15DDMC
PVQ41-1X/069-018RJ15LDMC
PVQ41-1X/082-018LJ15UDMC
PVQ41-1X/069-018LJ15LDMC
PVQ41-1X/098-018RJ15RUMC
PVQ41-1X/122-018RA15DDMC
PVQ41-1X/069-018LJ15LLMC
PVQ41-1X/122-036RA15DDMC
PVQ41-1X/122-018RJ15DDMC
PVQ41-1X/113-018RJ15UDMC
PVQ41-1X/069-018RJ15UUMC
PVQ41-1X/113-036RA15UUMC
PVQ42-1X/098-068LJ15RRMC
PVQ42-1X/082-068LJ15RRMC
PVQ42-1X/098-055LJ15RRMC
PVQ42-1X/122-068LA15DDMC
PVQ42-1X/122-068RA15DDMC
PVQ42-1X/098-068RA15UUMC
PVQ42-1X/098-055RA15DDMC
PVQ42-1X/082-040RA15DDMC
PVQ42-1X/082-068RA15DDMC
PVQ42-1X/122-045RA15DDMC
PVQ42-1X/098-068RA15DDMC
PVQ42-1X/122-068RA15RDMC
PVQ42-1X/069-040LJ15DDMC
PVQ42-1X/113-055RJ15DDMC
PVQ42-1X/113-040LJ15DDMC
PVQ42-1X/082-068RJ15UUVC
PVQ42-1X/082-068LJ15UUVC
PVQ42-1X/122-068RA15URMC
PVQ42-1X/082-060RA15UUMC
PVQ42-1X/113-068RB15URMC
PVQ42-1X/113-055LJ15DDMC
PVQ42-1X/113-060RA15DDMC
PVQ42-1X/098-068LJ15LLMC
PVQ42-1X/069-045RB15DDMC
PVQ42-1X/069-045RA15DDMC
PVQ42-1X/098-045RJ15DDMC
PVQ42-1X/098-055RA15RUMC
PVQ42-1X/069-060RJ15DDMC
PVQ42-1X/069-068RJ15DDMC
PVQ42-1X/069-068LJ15DDMC
PVQ42-1X/069-060RJ15RUMC
PVQ42-1X/122-040RA15RUMC
PVQ42-1X/113-040RA15RUMC
PVQ42-1X/082-045RA15UUMC
PVQ42-1X/122-045RB15DDMC
PVQ42-1X/122-060RB15DDMC
PVQ42-1X/113-068LA15DDMC
PVQ5-1X/193RJ15UMC
PVQ5-1X/193RA15DMC
PVQ5-1X/162RA15LMC
PVQ5-1X/162RA15UMC
PVQ5-1X/154RA15DMC
PVQ5-1X/139RA15DMC
PVQ5-1X/183RA15DMC
PVQ5-1X/193LB15UMC
PVQ5-1X/139RJ15UMC
PVQ5-1X/183RJ15UMC
PVQ5-1X/193RB15UMC
PVQ5-1X/162RJ15UMC
PVQ5-1X/162RA15DMC
PVQ5-1X/193RA15UMC
PVQ5-1X/193LA15UMC
PVQ5-1X/193RJ15DMC
PVQ5-1X/183RA15UMC
PVQ5-1X/193RA15UVC
PVQ5-1X/162LJ15LMC
PVQ5-1X/193RJ15UVC
PVQ5-1X/193LJ15DVC
PVQ5-1X/139RA15UMC
PVQ5-1X/193RJ15UMCK02
PVQ5-1X/193LJ15UMC
PVQ5-1X/162RJ15DMC
PVQ5-1X/154RB15UMC
PVQ5-1X/183RA15RMC
PVQ5-1X/154LJ15RMC
PVQ5-1X/183LJ15DVC
PVQ5-1X/139LJ15DMC
PVQ5-1X/193LJ15RMC
PVQ5-1X/154LA15DMC
PVQ5-1X/193RB15DVCK01
PVQ5-1X/139RB15DVCK01
PVQ5-1X/162RB15DMCK07
PVQ5-1X/193RJ15UMCK07
PVQ5-1X/162LJ15DMC
PVQ51-1X/139-040RA15DDMC
PVQ51-1X/193-036RA15DDMC
PVQ51-1X/162-036RJ15UDMC
PVQ51-1X/139-027RJ15UDMC
PVQ51-1X/154-036RJ15UDMC
PVQ51-1X/139-018LJ15DDMC
PVQ51-1X/193-018RJ15UDMC
PVQ51-1X/162-036RJ15DDMC
PVQ51-1X/193-027RJ15UDMC
PVQ51-1X/193-040RJ15UDMC
PVQ51-1X/193-018RB15UUMC
PVQ51-1X/193-018RB15DDMC
PVQ51-1X/154-027RJ15UDMC
PVQ51-1X/193-018LJ15DDMC
PVQ51-1X/162-040RB15UUMC
PVQ51-1X/193-027RB15RRVC
PVQ51-1X/193-040LJ15UDMC
PVQ51-1X/139-018RB15DDMC
PVQ51-1X/154-018RB15DDMC
PVQ51-1X/162-018RJ15DDMC
PVQ51-1X/193-027RJ15DDMC
PVQ51-1X/193-018RA15DDMC
PVQ51-1X/193-018RJ15DDMC
PVQ51-1X/193-027RB15DDMC
PVQ52-1X/139-068RA15DDMC
PVQ52-1X/139-040RA15DDMC
PVQ52-1X/162-068RA15DDMC
PVQ52-1X/183-068RA15DDMC
PVQ52-1X/162-045RB15RRVC
PVQ52-1X/139-040RA15UUMC
PVQ52-1X/193-040RJ15UDMC
PVQ52-1X/154-055RA15URMC
PVQ52-1X/193-068RB15UUMC
PVQ52-1X/193-055LJ15RRMC
PVQ52-1X/139-055RA15RUMC
PVQ52-1X/193-068RA15RUMC
PVQ52-1X/193-068RB15DDMC
PVQ52-1X/193-040RJ15RDMC
PVQ52-1X/193-040RJ15LLMC
PVQ52-1X/193-045RJ15UDMC
PVQ54-1X/139-113RB15DDMC
PVQ54-1X/139-082RA15DDMC
